The Talley Marlin Lever Action scope mount in medium 1-inch height (brand part no. 940336) is a one-piece ring-and-base mount made by Talley Manufacturing for Marlin lever action rifles, sized for 1-inch scope tubes at medium ring height in black anodized. The base and rings are one integrated piece, so the scope is not riding on a joint that can work loose or sit out of alignment as it can on a two-piece setup. The mount is CNC machined from high-grade aircraft aluminum, so it stays light on the rifle. No lapping is required, so it is ready to install out of the box. At medium height both the front and rear mounts measure 0.620-inch from the top of the receiver to the bottom of the scope tube, and a set weighs 2.1 oz for 1-inch tubes. It suits a hunting or range rifle that needs a light, solid scope platform on Marlin lever action rifles.

Key Specifications

• The mount is designed to fit Marlin Lever Action models 1895, 336 and 1894, so the base footprint matches those actions.
• The design is a one-piece ring and base, which keeps the rings aligned with the base.
• The ring size is 1-inch, matched to 1-inch scope main tubes.
• The ring height is Medium, which sets how far the scope sits above the receiver.
• Both the front and rear mount heights are 0.620-inch, measured from the top of the receiver to the bottom of the scope tube.
• A set weighs 2.1 oz with 1-inch rings, light enough to keep the rifle balanced.
• The material is CNC-machined aircraft-grade aluminum, which holds tight tolerances at low weight.
• The finish is black anodized, a durable surface for the aluminum.
• Mounting hardware is 8-40 screws and a T-15 wrench, supplied with the mount.
• The hole spacing is 0.500-inch front and rear, measured center to center, which has to match the receiver.

Frequently Asked Questions

How is the ring height measured? Height is measured from the top of the action or receiver to the bottom of the scope tube at the respective mounting location. This medium version measures 0.620-inch at both the front and rear.

What scope tube size does this medium mount take? This version is sized for 1-inch scope main tubes at medium ring height.

Which rifles does this mount fit? It is designed to fit Marlin Lever Action models 1895, 336 and 1894.
