The EOTech DCBL 556 black titanium suppressor is a 3D-printed Grade 5 titanium can for an AR-15 or other 5.56 rifle (EOTech part no. EOT-DCBL-556-MB). EOTech built the DCBL line around a vent-forward design that sends gas forward and away from the shooter, cutting back pressure and blowback for cleaner cycling. The body is 7.1 inches long and weighs 13.7 ounces, and EOTech also publishes the working figures with the hub or flash hider fitted: 7.9 inches and 19.6 ounces. It mounts on the standard 1.375-24 HUB thread, so common HUB mounts and adapters fit. This version carries a black high-temperature Cerakote finish.

Key Specifications

• EOTech lists the maximum caliber as .22 Creedmoor, the largest cartridge rated for this model.
• Bore diameter is 0.283 inch, the opening the bullet passes through.
• The suppressor body is 7.1 inches long before the hub or flash hider is added.
• Installed length with the hub or flash hider is 7.9 inches, the figure to plan around on your rifle.
• Overall diameter is 1.75 inches, so check handguard and optic clearance before mounting.
• The body alone weighs 13.7 ounces, a figure EOTech publishes without the hub.
• Installed weight with the hub or flash hider is 19.6 ounces, the real weight added at the muzzle.
• Construction is 3D-printed Grade 5 titanium, which allows baffle shapes that conventional machining cannot produce.
• The finish is black high-temperature Cerakote, a coating that stands up to suppressor heat.
• Mounting uses the 1.375-24 HUB thread, the industry standard that accepts common HUB mounts.

Frequently Asked Questions

What rifles is the black DCBL 556 made for? It is sized for 5.56 rifles such as the AR-15, and EOTech lists its maximum caliber as .22 Creedmoor.

Do I need ATF approval to buy this? No. As of October 9, 2026, ATF no longer requires Form 4 approval, registration or a tax stamp for suppressors. It transfers on a Form 4473 with a background check through a Class 3 (SOT) dealer. State and local laws still apply.

Is there a minimum barrel length? EOTech lists a minimum barrel length of 10.3 inches for the DCBL 556, and the suppressor is listed as not full-auto rated.

Buy the EOTech DCBL 556 Black Titanium Suppressor

As of October 9, 2026, this suppressor transfers on a Form 4473 with a background check at your Class 3 (SOT) dealer, with no Form 4 or tax stamp; state and local laws still apply. Order through EOTech‘s suppressor lineup and our Lubbock, Texas team will handle the transfer.
