The Bushnell R5 4-12×40 DOA-LRH800 Illuminated Riflescope (Bushnell part no. R5-41240S25) gives hunters more reach than a 3-9 without moving to a big objective. Its DOA-LRH800 reticle is illuminated and carries BDC drop points out to 800 yards with 5 and 10 MPH wind holds. HD glass, fully multi-coated optics and EXO Barrier protection produce a clear, bright view, while side focus lets you sharpen the image at any distance. Target turrets make repeatable adjustments easy in the field. Bushnell stands behind it with a Lifetime Warranty.

Key Specifications

• Magnification runs 4-12x, extra reach for open-country shots.
• The objective lens is 40mm, which keeps the scope slim and low on the rifle.
• The reticle is the illuminated DOA-LRH800, with BDC drop points to 800 yards.
• Focal plane is second, so the reticle appears the same size at every power.
• The tube is 1 inch in diameter, matching 1-inch rings.
• Eye relief is 4.0 inches, comfortable under recoil.
• Field of view is 27 feet at 100 yards at 4x and 9 feet at 12x.
• Each click is 0.25 MOA, under capped target turrets.
• Elevation and windage each have 70 MOA of adjustment range.
• Illumination uses an included 2032 battery, with off positions between brightness settings.

Frequently Asked Questions

What is the maximum magnification? The scope zooms from 4x to 12x with a 40mm objective lens.

Does the reticle have drop points? Yes. The illuminated DOA-LRH800 has BDC drop points out to 800 yards, with 5 and 10 MPH wind holds.

What ring size does it need? The tube is 1 inch, so 1-inch rings are the right size.

Buy the Bushnell R5 4-12×40 DOA-LRH800 Illuminated Riflescope

For deer and hog hunters who stretch past a typical 3-9 range, the 4-12×40 R5 adds magnification and a lit ballistic reticle at a modest size. Order it with other gun scopes from our Lubbock, Texas gun shop for fast shipping.
