Description

The American Defense AD-1700-XLR QD riser is an extended-length Picatinny riser that lifts an optic 0.60 inch above the mounting surface (brand part no. AD-1700-XLR-STD). Its 5.5-inch overall length and forward cantilever push the optic out over the handguard, the layout used with helmet-mounted night vision devices. American Defense CNC machines it from 6061-T6 aluminum, finishes it in hard coat anodize and locks it to the rail with the patented QD Auto Lock lever. The optic rail on top slides forward and back, so the shooter sets the position instead of accepting a fixed one. The maker points to EOTech XPS and EXPS holographic sights paired with a magnifier as a natural fit.

Key Specifications

  • The riser lifts the optic 0.60 inch above the mounting surface, which raises the line of sight over the rail below it.
  • Overall rail length is 5.5 inches, long enough to carry a sight and magnifier combination on one piece of rail.
  • A forward cantilever pushes the optic out over the handguard, which is how the mount makes room for helmet-mounted night vision devices.
  • Centerline height is 2 inches with EOTech 512 and XPS models and 2.33 inches with the EXPS, so the sight height is known before the mount is ordered.
  • The mount is precision CNC machined from 6061-T6 aluminum, a strong, light alloy that holds up to rail use.
  • The patented QD Auto Lock lever clamps it to the rail with a superior clamping surface and works on both in-spec and out-of-spec rails.
  • Weight is 5.6 ounces, light for a riser of this length.

Frequently Asked Questions

Which sights is the AD-1700-XLR made for? The maker lists it as a fit for EOTech XPS and EXPS holographic sights and magnifier combinations. Centerline height is 2 inches with the 512 and XPS models and 2.33 inches with the EXPS.

Does the optic rail move? Yes. The optic rail is adjustable forward and backward, so the shooter can set the position to suit the rifle and the sight.

How does the QD lever work? The patented QD Auto Lock lever needs no proprietary tools. It adjusts by finger or with a flat blade screwdriver, can be set to lock to the front or the rear, and fits both in-spec and out-of-spec rail systems.

Buy the American Defense AD-1700-XLR QD Riser, 0.60-Inch Rise

Getting a magnifier and a night vision device onto one rail comes down to rail length and forward reach, and this riser supplies both in a single machined piece. Order it from our Lubbock, Texas gun shop for fast, insured shipping, and see the rest of our scope mounts while you are here.

Additional Information

UPC

810104930888

Manufacturer

American Defense Mfg

Manufacturer Part Number

AD-1700-XLR-STD

Model

AD-1700

Product Type

Riser
